Littelfuse_498規(guī)格書Interrupting Rating:2000A @ 32 VDC
Voltage Rating: 32VDC
Operating Temperature Range：-40 ?C to +125 ?C
| Part Number | Current Rating (A) | Test. Cable Size(mm2) | Typ. Voltage Drop(mV) | Typ. Cold Resistance (mΩ) | Typ.I2t(A2s) |
| 0498030._ | 30 | 2.5 | 65 | 2.06 | 4200 |
| 0498040._ | 40 | 4 | 65 | 1.40 | 10000 |
| 0498050_ | 50 | 6 | 65 | 1.02 | 13000 |
| 0498060._ | 60 | 6 | 68 | 0.87 | 21700 |
| 0498070._ | 70 | 10 | 70 | 0.72 | 24000 |
| 0498080._ | 80 | 10 | 58 | 0.54 | 24600 |
| 0498100._ | 100 | 16 | 60 | 0.46 | 51300 |
| 0498125._ | 125 | 25 | 71 | 0.39 | 73200 |
| 0498150._ | 150 | 25 | 77 | 0.32 | 81900 |
| 0498175._ | 175 | 25 | 77 | 0.26 | 100000 |
| 0498200._ | 200 | 25 | 77 | 0.26 | 125000 |
